Model NO.: Us-25
Power Supply: AC or DC
Usage: Flow Control
Standard: GB
Application: Industrial Usage, Water Industrial Usage, Household Usage
Fluid: Steam,Air, Water
Operating Speed: 50~500mm/S
Delivery Time: Within 20 Days
Port Size: 1/8" , 1/4"
Trademark: WIIKADE
Transport Package: Plastic Bag & Carton
Specification: CE, ISO, RoHS
Origin: China
HS Code: 8481804090
Model NO.: Us-25
Power Supply: AC or DC
Usage: Flow Control
Standard: GB
Application: Industrial Usage, Water Industrial Usage, Household Usage
Fluid: Steam,Air, Water
Operating Speed: 50~500mm/S
Delivery Time: Within 20 Days
Port Size: 1/8" , 1/4"
Trademark: WIIKADE
Transport Package: Plastic Bag & Carton
Specification: CE, ISO, RoHS
Origin: China
HS Code: 8481804090
Steam solenoid valve 110V coils US 2L-25
Working medium: Steam, high temperature liquid oil<20CST
Medium temperature: -5~180º C
Working pressure: 0.1~1.5 bar
Work style: Normally closed
Valve body material: Brass
Sealing material: PTFE
Coil parameters: AC220V/110V 50/60HZ DC 24V/12V, available for other voltages
Have stock for more than 100 pieces
Payment: Bank T/T, Western Union or Paypal, L/C
Model |
US-10 | US-15 | US-20 | US-25 | US-35 | US-40 | US-50 |
working medium | air | water | steam | Â | Â | Â | Â |
motion parttern | guide | type | Â | Â | Â | Â | Â |
Type | NC | type | Â | Â | Â | Â | Â |
Flow rate(mm) | 17 | 17 | 17 | 20 | 30 | 30 | 50 |
CV value | 4.8 | 4.8 | 4.8 | 12 | 20 | 20 | 48 |
joint pipe bore | 3/8'' | 1/2'' | 3/4'' | 1'' | 1 1/4'' | 1 1/2'' | 2'' |
Operation fluid Viscosity | 20CST | Â | Â | Â | Â | Â | Â |
working pressure | 1~15 | kgf/cm2 | Â | Â | Â | Â | Â |
Max.Pressure | 22.5 | kgf/cm2 | Â | Â | Â | Â | Â |
operating temp. | -5~+180 | C | Â | Â | Â | Â | Â |
Material of oil seal | PTFE Â |
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.Â
Ningbo Wiikade Trading Co., Ltd. is a research and development, productions and sales of two position two way solenoid valve and pneumatic cylinder professional company, the company has more than ten years of production experience, exquisite, high quality, complete varieties and specifications. The products are widely used in machinery, textile, chemical industry, environmental protection, food and other fields.Â
Depending on the quality of such a life, as our goal to produce first-class products. Comprehensive ISO9001 quality management system to organize production, testing, sales and after-sales service. Sophisticated machinery and equipment, advanced production technology, strong technical force, the detection means complete, and after-sales service system is sound. We insist on the principle of "customer first"for each customer to provide high-quality, full range of services. WIIKADE heavy credibility, quality, heavy service, product structure, technology leadership, quality excellence, trust and praise by the customers. The products have been exported to the United States, France, Britain, Germany, Italy, Russia, the Middle East, Taiwan and other countries and regions.Â
We are willing to work together with all care WIIKADE, trust WIIKADE friends to join hands in creating a brilliant tomorrow!Â
